Solar Mas 1S Pro Microinverter
A 1kW microinverter that runs two solar panels independently, each on its own MPPT tracker. Sized for smaller roofs and first solar systems, and built to keep generating when one panel is shaded or fails. Sub-1G and WiFi monitoring, 96.7% peak efficiency, and an IP67 housing rated from -40 to +65°C.
- Category:
- Grid-Tied Inverters
Product Specifications
- Model
- HYX-M1000-S
- Nominal Output Power
- 1,000VA
- PV Modules Supported
- 2
- Typical Module Compatibility
- 400 to 670+ W
- MPPT Voltage Range
- 16 to 60V
- Max. Input Voltage
- 65V
- Start-up Input Voltage
- 20V
- Max. Input Current
- 2 x 16A
- Max. Short-circuit DC Input Current
- 2 x 20A
- Nominal Output Voltage
- 220V / 230V / 240V
- Nominal Output Current
- 4.55A / 4.35A / 4.17A
- Adjustable Output Voltage Range
- 183 to 276V
- Nominal Frequency
- 50 / 60Hz
- Power Factor
- Over 0.99 by default, adjustable from 0.8 leading to 0.8 lagging
- THDi
- Under 3%
- Max. Units Per Branch
- 6 on 10AWG, 4 to 5 on 12AWG
- Peak Efficiency
- 96.70%
- Nominal MPPT Efficiency
- 99.80%
- Night-time Power Loss
- Under 30mW
- Operating Ambient Temperature
- -40 to +65°C
- Dimensions (W x H x D)
- 252 x 180 x 35mm
- Weight
- 3kg
- Degree of Protection
- IP67
- Cooling
- Natural cooling, no fans
- Communication
- Sub-1G or built-in WiFi
- Type of Isolation
- High-frequency transformers, galvanically isolated
- Protection
- Input reverse connection, output overcurrent, output overvoltage, anti-islanding, output short-circuit
- Warranty
- 12 years standard, 25 years optional
